Please contact us for more photos of OPA690IDBVR
| Part Number | OPA690IDBVR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 184360 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Single Volt Fdbk \u00b16V 12V 6-Pin SOT-23 T R |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | OPA690IDBVR |
| Datasheet download |  OPA690IDBVR.pdf |
| Part Number | OPA690IDBVR |
|---|---|
| Typical Slew Rate | 1000@5V V/us |
| Rail to Rail | No |
| Minimum Dual Supply Voltage | ±2.5 V |
| Typical Voltage Gain | 63 dB |
| Max Processing Temp | 260|300 |
| Mounting | Surface Mount |
| Product Dimensions | 2.9 x 1.6 x 1.15 mm |
| Typical NonInverting Input Noise Current Density | 3.2@5V pA/rtHz |
| Power Supply Type | Single|Dual |
| Pin Count | 6 |
| Type | Voltage Feedback Amplifier |
| Number of Channels per Chip | 1 |
| Minimum Single Supply Voltage | 5 V |
| Maximum Dual Supply Voltage | ±6 V |
| Typical Gain Bandwidth Product | 250 MHz |
| Maximum Single Supply Voltage | 12 V |
| Maximum Operating Supply Voltage | ±6|12 V |
| Supplier Package | SOT-23 |
| Maximum Input Bias Current | 10@5V uA |
| MSL Level | 2 |
| Minimum CMRR | 58 dB |
| Typical Dual Supply Voltage | ±3|±5 V |
| Lead Finish | Gold |
| Operating Temperature | -40 to 85 °C |
| Rad Hard | No |
| Typical Single Supply Voltage | 9 V |
| Maximum Input Offset Voltage | 4@5V mV |
| Minimum PSRR | 72 dB |
| Typical Input Noise Voltage Density | 5.6@5V nV/rtHz |
| Technology | BiCOM |
| Shut Down Support | Yes |
| Package | 6SOT-23 |
| Replacement Part Number | PART-OPA690IDBVR |
| Weight | Contact us |
| Country of Origin | - |
