Please contact us for more photos of PCA9536DGKR
| Part Number | PCA9536DGKR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 482540 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Remote I2C and SMBus I O Expander 8-Pin VSSOP T R |
| Category | Interface IC |
| Family | Interface Misc |
| ROHS Compliant | Yes |
| MSL Level | PCA9536DGKR |
| Datasheet download |  PCA9536DGKR.pdf |
| Part Number | PCA9536DGKR |
|---|---|
| Category | Remote I2C and SMBus I/O Expander |
| Type | Remote I2C and SMBus I/O Expander |
| Supplier Package | VSSOP |
| Operating Temperature | -40 to 85 °C |
| Product Dimensions | 3 x 3 x 0.97 mm |
| Pin Count | 8 |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Mounting | Surface Mount |
| Lead Finish | Gold |
| Package | 8VSSOP |
| Replacement Part Number | PART-PCA9536DGKR |
| Weight | Contact us |
| Country of Origin | - |
