Please contact us for more photos of PTH08080WAH
| Part Number | PTH08080WAH |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 565730 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Module DC-DC 1-OUT 0.9V to 5.5V 2.25A 10W 5-Pin DIP Module Tray |
| Category | Power Supplies |
| Family | DC to DC Power Supply |
| ROHS Compliant | Yes |
| MSL Level | PTH08080WAH |
| Datasheet download |  PTH08080WAH.pdf |
| Part Number | PTH08080WAH |
|---|---|
| Output Current | 2.25 A |
| Input Voltage | 4.5 to 18 V |
| Max Processing Temp | 235 |
| Type | Step Down |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Output Voltage | 0.9 to 5.5 V |
| Output Power | 10 W |
| Supplier Package | DIP Module |
| Mounting | Through Hole |
| Number of Outputs | 1 |
| Pin Count | 5 |
| Product Dimensions | 15.24 x 12.7 x 7.93 mm |
| Switching Regulator | Yes |
| Package | 5DIP Module |
| Replacement Part Number | PART-PTH08080WAH |
| Weight | Contact us |
| Country of Origin | - |
