Please contact us for more photos of PTH08T220WAS
| Part Number | PTH08T220WAS |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 150180 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Module DC-DC 1-OUT 0.69V to 5.5V 16A 11-Pin DIP Module Tray |
| Category | Power Supplies |
| Family | DC to DC Power Supply |
| ROHS Compliant | Yes |
| MSL Level | PTH08T220WAS |
| Datasheet download |  PTH08T220WAS.pdf |
| Part Number | PTH08T220WAS |
|---|---|
| Supplier Package | DIP Module |
| Mounting | Surface Mount |
| Type | Step Down |
| Number of Outputs | 1 |
| Pin Count | 11 |
| Output Voltage | 0.69 to 5.5 V |
| Input Voltage | 4.5 to 14 V |
| MSL Level | 1 |
| Lead Finish | Tin/Lead |
| Switching Regulator | Yes |
| Output Current | 16 A |
| Product Dimensions | 22.1 x 18.93 x 8.25 mm |
| Rad Hard | No |
| Max Processing Temp | 235 |
| Package | 11DIP Module |
| Replacement Part Number | PART-PTH08T220WAS |
| Weight | Contact us |
| Country of Origin | - |
