PTH08T260WAD Texas Instruments

PTH08T260WAD Images

Please contact us for more photos of PTH08T260WAD

Part Number	PTH08T260WAD
Manufacturer	Texas Instruments
Quantity in stock	617280 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Module DC-DC 1-OUT 0.69V to 5.5V 3A 10-Pin DIP Module
Category	Power Supplies
Family	DC to DC Power Supply
ROHS Compliant	Yes
MSL Level	PTH08T260WAD
Datasheet download	PTH08T260WAD.pdf

Request Quotation for PTH08T260WAD

PTH08T260WAD Specifications

Part Number	PTH08T260WAD
Supplier Package	DIP Module
Switching Regulator	No
Max Processing Temp	260
Rad Hard	No
Lead Finish	Matte Tin
Output Current	3 A
Type	Step Down
Number of Outputs	1
Mounting	Through Hole
Input Voltage	4.5 to 14 V
Pin Count	10
Product Dimensions	18.92 x 15.75 x 7.5 mm
Output Voltage	0.69 to 5.5 V
Package	10DIP Module
Replacement Part Number	PART-PTH08T260WAD
Weight	Contact us
Country of Origin	-
