SN6505BDBVR Texas Instruments

SN6505BDBVR Images

Please contact us for more photos of SN6505BDBVR

Part Number SN6505BDBVR
Manufacturer Texas Instruments
Quantity in stock 445810 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Conv DC-DC Single Non-Inverting Inverting Step Up Step Down 2.2V to 5.5V 6-Pin SOT-23 T R
Category Power Supplies
Family Power Misc
ROHS Compliant Yes
MSL Level SN6505BDBVR
Datasheet download SN6505BDBVR.pdf
Request Quotation for SN6505BDBVR

SN6505BDBVR Specifications

Part Number SN6505BDBVR
Operating Temperature -55 to 125 °C
Rad Hard No
Mounting Surface Mount
Switching Frequency 424 kHz
MSL Level 1
Type Non-Inverting|Inverting|Step Up|Step Down
Lead Finish Gold Over Nickel Palladium
Operating Supply Voltage 2.25 to 5.5 V
Output Voltage 0 to 16 V
Supplier Package SOT23
Pin Count 6
Max Processing Temp 260
Output Type Adjustable
Number of Outputs 1
Maximum Output Current 1 A
Maximum Input Voltage 5.5 V
Screening Level Military
Minimum Input Voltage 2.2 V
Product Dimensions 2.9 x 1.6 x 1.3(Max)
Package 6SOT-23
Replacement Part Number PART-SN6505BDBVR
Weight Contact us
Country of Origin -
