Please contact us for more photos of SN65LBC179QDR
| Part Number | SN65LBC179QDR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 542400 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Single Transmitter Receiver RS-485 8-Pin SOIC T R |
| Category | Communication |
| Family | Bus Line Transceiver |
| ROHS Compliant | Yes |
| MSL Level | SN65LBC179QDR |
| Datasheet download |  SN65LBC179QDR.pdf |
| Part Number | SN65LBC179QDR |
|---|---|
| Number of Transmitter Enables | 0 |
| Number of Receivers per Line | 32 |
| Mounting | Surface Mount |
| ESD Protection | No |
| Receiver Communication Type | RS-485 |
| Minimum Single Supply Voltage | 4.75 V |
| Maximum Single Supply Voltage | 5.25 V |
| Power Supply Type | Single |
| Number of Receiver Enables | 0 |
| Number of Transmitters | 1 |
| MSL Level | 1 |
| Pin Count | 8 |
| Data Rate | 10 Mbps |
| Data Transmission Topology | Multipoint |
| Supplier Package | SOIC |
| Screening Level | Automotive |
| Rad Hard | No |
| Lead Finish | Gold |
| Operating Temperature | -40 to 125 °C |
| Max Processing Temp | 260 |
| Number of Drivers per Line | 32 |
| Driving Mode | No |
| Maximum Supply Current | 7 mA |
| Typical Single Supply Voltage | 5 V |
| Transmitter Communication Type | RS-485 |
| Interface Standards | ISO-8482|RS-485 |
| Number of Transceivers | 1 |
| Product Dimensions | 5 x 4 x 1.5 mm |
| Function | Line Transmitter/Receiver |
| Receiver Signal Type | Differential |
| Transmitter Signal Type | Differential |
| Number of Receivers | 1 |
| Package | 8SOIC |
| Replacement Part Number | PART-SN65LBC179QDR |
| Weight | Contact us |
| Country of Origin | - |
