SN65LVDS2DR Texas Instruments

Please contact us for more photos of SN65LVDS2DR

Part Number	SN65LVDS2DR
Manufacturer	Texas Instruments
Quantity in stock	504680 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LVDS Driver Receiver 0.454V 8-Pin SOIC T R
Category	Interface IC
Family	LVDS
ROHS Compliant	Yes
MSL Level	SN65LVDS2DR
Datasheet download	SN65LVDS2DR.pdf

Request Quotation for SN65LVDS2DR

SN65LVDS2DR Specifications

Part Number	SN65LVDS2DR
Number of Elements per Chip	1
Mounting	Surface Mount
Maximum Operating Supply Voltage	3.6 V
Output Type	Driver/Receiver
Maximum Propagation Delay Time	3.1 ns
MSL Level	1
Pin Count	8
Supplier Package	SOIC
Input Type	LVDS
Maximum Input Current	20 uA
Number of Drivers	1
Minimum Operating Supply Voltage	2.4 V
Maximum Differential Output Voltage	0.454 V
Typical Operating Supply Voltage	3.3 V
Operating Temperature	-40 to 85 °C
Maximum Power Dissipation	725 mW
Product Dimensions	5 x 4 x 1.5 mm
Differential Input High Threshold Voltage	0.1 V
Max Processing Temp	260
Lead Finish	Gold
Rad Hard	No
Transmission Data Rate	400 Mbps
Number of Receivers	1
Differential Input Low Threshold Voltage	-0.1 V
Package	8SOIC
Replacement Part Number	PART-SN65LVDS2DR
Weight	Contact us
Country of Origin	-
