Please contact us for more photos of TAS5766MRMTR
| Part Number | TAS5766MRMTR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 773070 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Audio Amp Speaker 2-CH Stereo 50W Class-D 48-Pin VQFN EP T R |
| Category | Amplifiers IC |
| Family | Audio Amplifier |
| ROHS Compliant | Yes |
| MSL Level | TAS5766MRMTR |
| Datasheet download |  TAS5766MRMTR.pdf |
| Part Number | TAS5766MRMTR |
|---|---|
| Amplifier Type | Class-D |
| Rail to Rail | No |
| Output Type | 2-Channel Stereo |
| Pin Count | 48 |
| Minimum Dual Supply Voltage | 3|4.5 V |
| Power Supply Type | Quint |
| Maximum Load Resistance | 8 Ohm |
| Maximum Dual Supply Voltage | 3.6|26.4 V |
| Supplier Package | VQFN EP |
| Maximum Supply Current | [email protected] mA |
| Function | Speaker |
| Typical Output Power x Channels @ Load | 50x2@4Ohm W |
| Input Signal Type | Single |
| Typical Dual Supply Voltage | 3.3|5|9|12|15|18|24 V |
| Output Signal Type | Differential |
| Product Dimensions | 7 x 5 x 0.95(Max) |
| Typical Supply Current | [email protected] mA |
| Maximum Output Current | 7500 mA |
| Lead Finish | Gold Over Nickel Palladium |
| Screening Level | Industrial |
| Maximum Input Offset Voltage | 15@24V mV |
| Total Harmonic Distortion Noise | 0.05@8Ohm@1W % |
| Rad Hard | No |
| Mounting | Surface Mount |
| MSL Level | 3 |
| Operating Temperature | -25 to 85 °C |
| Max Processing Temp | 260 |
| Package | 48VQFN EP |
| Replacement Part Number | PART-TAS5766MRMTR |
| Weight | Contact us |
| Country of Origin | - |
