Please contact us for more photos of TL084ACDR
| Part Number | TL084ACDR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 162780 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Quad GP \u00b118V 14-Pin SOIC T R |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | TL084ACDR |
| Datasheet download |  TL084ACDR.pdf |
| Part Number | TL084ACDR |
|---|---|
| Typical Voltage Gain | 106.02 dB |
| Minimum Dual Supply Voltage | ±3.5 V |
| Mounting | Surface Mount |
| Pin Count | 14 |
| Maximum Input Offset Voltage | 6@±15V mV |
| Technology | BiFET |
| Type | General Purpose Amplifier |
| Maximum Operating Supply Voltage | ±18 V |
| Shut Down Support | No |
| Number of Channels per Chip | 4 |
| MSL Level | 1 |
| Maximum Power Dissipation | 680 mW |
| Supplier Package | SOIC |
| Typical Gain Bandwidth Product | 3 MHz |
| Minimum CMRR | 75 dB |
| Typical Slew Rate | 13@±15V V/us |
| Maximum Dual Supply Voltage | ±18 V |
| Product Dimensions | 8.75 x 4 x 1.5 mm |
| Maximum Input Bias Current | 0.0002@±15V uA |
| Typical Dual Supply Voltage | ±5|±9|±12|±15 V |
| Typical NonInverting Input Noise Current Density | 0.01@±15V pA/rtHz |
| Operating Temperature | 0 to 70 °C |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Lead Finish | Gold |
| Rail to Rail | No |
| Typical Input Noise Voltage Density | 18@±15V nV/rtHz |
| Maximum Supply Current | 11.2@±15V mA |
| Power Supply Type | Dual |
| Package | 14SOIC |
| Replacement Part Number | PART-TL084ACDR |
| Weight | Contact us |
| Country of Origin | - |
