Please contact us for more photos of TL2575HV-15IKTTR
| Part Number | TL2575HV-15IKTTR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 679710 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.75V to 60V 6-Pin(5+Tab) TO-263 T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | TL2575HV-15IKTTR |
| Datasheet download |  TL2575HV-15IKTTR.pdf |
| Part Number | TL2575HV-15IKTTR |
|---|---|
| Maximum Output Current | 1 A |
| Switching Frequency | 58 kHz |
| Efficiency | 88 % |
| Type | Step Down |
| Rad Hard | No |
| Pin Count | 6 |
| Number of Outputs | 1 |
| Switching Regulator | Yes |
| Max Processing Temp | 245 |
| Mounting | Surface Mount |
| Operating Supply Voltage | 4.75 to 60 V |
| Lead Finish | Tin |
| Output Voltage | 15 V |
| MSL Level | 3 |
| Minimum Input Voltage | 4.75 V |
| Operating Temperature | -40 to 125 °C |
| Product Dimensions | 10.16 x 8.42 x 4.58 mm |
| Output Type | Fixed |
| Maximum Input Voltage | 60 V |
| Supplier Package | TO-263 |
| Package | 6TO-263 |
| Replacement Part Number | PART-TL2575HV-15IKTTR |
| Weight | Contact us |
| Country of Origin | - |
