| Part Number | TLC3548IDWR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 846670 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 200ksps 14-bit Serial 24-Pin SOIC T R |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | TLC3548IDWR |
| Datasheet download |  TLC3548IDWR.pdf |
| Part Number | TLC3548IDWR |
|---|---|
| Number of ADCs | 1 |
| Rad Hard | No |
| Input Signal Type | Single-Ended|Pseudo-Differential |
| Differential Input | Yes |
| Digital Supply Support | Yes |
| Maximum Single Supply Voltage | 5.5 V |
| Product Dimensions | 15.4 x 7.52 x 2.35 mm |
| Voltage Supply Source | Analog and Digital |
| Integral Nonlinearity Error | ±1 LSB |
| Sampling Rate | 200 ksps |
| Digital Interface Type | Serial (3-Wire, SPI) |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Resolution | 14 Bit |
| Lead Finish | Gold |
| Input Voltage | 4 V |
| No Missing Codes | 14 Bit |
| Single-Ended Input | Yes |
| Signal to Noise Ratio | 81 dB |
| Architecture | SAR |
| Screening Level | Industrial |
| Pin Count | 24 |
| Mounting | Surface Mount |
| Input Type | Voltage |
| Polarity of Input Voltage | Unipolar |
| Sample and Hold | Yes |
| Full Scale Error | 12 LSB |
| Differential Nonlinearity | ±1 LSB |
| Minimum Single Supply Voltage | 4.5 V |
| MSL Level | 1 |
| Typical Single Supply Voltage | 5 V |
| Voltage Reference | Internal|External |
| Number of Analog Inputs | 8|4 |
| Supplier Package | SOIC |
| Package | 24SOIC |
| Replacement Part Number | PART-TLC3548IDWR |
| Weight | Contact us |
| Country of Origin | - |
