Please contact us for more photos of TLE2142CPWR
| Part Number | TLE2142CPWR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 776950 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Dual GP \u00b122V 44V 16-Pin TSSOP T R |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | TLE2142CPWR |
| Datasheet download |  TLE2142CPWR.pdf |
| Part Number | TLE2142CPWR |
|---|---|
| Maximum Input Bias Current | 2@5V uA |
| Maximum Single Supply Voltage | 44 V |
| Maximum Operating Supply Voltage | ±22|44 V |
| Mounting | Surface Mount |
| Minimum Dual Supply Voltage | ±2 V |
| Typical Voltage Gain | 106.85 dB |
| Minimum Single Supply Voltage | 4 V |
| Supplier Package | TSSOP |
| Type | General Purpose Amplifier |
| Technology | BiCOM |
| Shut Down Support | No |
| Typical Slew Rate | 45@5V V/us |
| Maximum Input Offset Voltage | 1.9@5V mV |
| Product Dimensions | 5.1 x 4.5 x 1.05 mm |
| Typical Single Supply Voltage | 5|9|12|15|18|24|28 V |
| Typical Dual Supply Voltage | ±3|±5|±9|±12|±15|±18 V |
| Typical Gain Bandwidth Product | 5.8 MHz |
| MSL Level | 1 |
| Typical NonInverting Input Noise Current Density | 1.92@5V pA/rtHz |
| Number of Channels per Chip | 2 |
| Power Supply Type | Single|Dual |
| Pin Count | 16 |
| Maximum Dual Supply Voltage | ±22 V |
| Minimum CMRR | 85 dB |
| Maximum Supply Current | 8.8@5V mA |
| Lead Finish | Gold |
| Max Processing Temp | 260 |
| Rail to Rail | No |
| Operating Temperature | 0 to 70 °C |
| Rad Hard | No |
| Typical Input Noise Voltage Density | 15@5V nV/rtHz |
| Package | 16TSSOP |
| Replacement Part Number | PART-TLE2142CPWR |
| Weight | Contact us |
| Country of Origin | - |
