Please contact us for more photos of TLV2382ID
| Part Number | TLV2382ID |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 751280 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Dual GP R-R I O \u00b18V 16V 8-Pin SOIC Tube |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | TLV2382ID |
| Datasheet download |  TLV2382ID.pdf |
| Part Number | TLV2382ID |
|---|---|
| Maximum Input Offset Voltage | 4.5@5V mV |
| Max Processing Temp | 260 |
| Power Supply Type | Single|Dual |
| Typical Gain Bandwidth Product | 0.16 MHz |
| Minimum Single Supply Voltage | 2.7 V |
| Supplier Package | SOIC |
| Technology | BiCMOS |
| Rail to Rail | Rail to Rail Input/Output |
| Minimum CMRR | 58 dB |
| Typical Slew Rate | 0.06@5V V/us |
| Product Dimensions | 5 x 4 x 1.5 mm |
| Maximum Dual Supply Voltage | ±8 V |
| Shut Down Support | No |
| Maximum Single Supply Voltage | 16 V |
| Number of Channels per Chip | 2 |
| Typical Dual Supply Voltage | ±3|±5 V |
| Minimum Dual Supply Voltage | ±1.35 V |
| Maximum Power Dissipation | 710 mW |
| Typical Voltage Gain | 100 dB |
| Maximum Input Bias Current | 0.00006@5V uA |
| Typical Input Noise Voltage Density | 90@5V nV/rtHz |
| Rad Hard | No |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Operating Temperature | -40 to 125 °C |
| Typical Single Supply Voltage | 3|5|9|12|15 V |
| Lead Finish | Gold |
| Screening Level | Industrial |
| Pin Count | 8 |
| Maximum Operating Supply Voltage | ±8|16 V |
| Minimum PSRR | 74 dB |
| Type | General Purpose Amplifier |
| Maximum Supply Current | 0.02@5V mA |
| Package | 8SOIC |
| Replacement Part Number | PART-TLV2382ID |
| Weight | Contact us |
| Country of Origin | - |
