TLV5614ID Texas Instruments

TLV5614ID Images

Please contact us for more photos of TLV5614ID

Part Number TLV5614ID
Manufacturer Texas Instruments
Quantity in stock 286110 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description DAC 4-CH Resistor-String 12-bit 16-Pin SOIC Tube
Category Data Conversion IC
Family DAC
ROHS Compliant Yes
MSL Level TLV5614ID
Datasheet download TLV5614ID.pdf
Request Quotation for TLV5614ID

TLV5614ID Specifications

Part Number TLV5614ID
Number of DAC Channels 4
Mounting Surface Mount
Full Scale Error 0.6 % of FSR
Digital Interface Type Serial (3-Wire, 4-Wire, SPI, QSPI, Microwire)
Power Supply Type Analog|Digital
Resolution 12 Bit
Output Polarity Unipolar
Number of Outputs per Chip 4
MSL Level 1
Supplier Package SOIC
Typical Single Supply Voltage 3|5 V
Signal to Noise Ratio 74 dB
Lead Finish Gold
Conversion Rate 102 ksps
Maximum Settling Time 20 us
Pin Count 16
Product Dimensions 10 x 4 x 1.5 mm
Integral Nonlinearity Error ±4 LSB
Digital Supply Support Yes
Maximum Single Supply Voltage 5.5 V
Voltage Reference External
Output Type Voltage
Architecture Resistor-String
Max Processing Temp 260
Operating Temperature -40 to 85 °C
Rad Hard No
Minimum Single Supply Voltage 2.7 V
Package 16SOIC
Replacement Part Number PART-TLV5614ID
Weight Contact us
Country of Origin -
