| Part Number | TPA3101D2RGZT |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 579380 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Audio Amp Speaker 2-CH Stereo 10W Class-D 48-Pin VQFN EP T R |
| Category | Amplifiers IC |
| Family | Audio Amplifier |
| ROHS Compliant | Yes |
| MSL Level | TPA3101D2RGZT |
| Datasheet download |  TPA3101D2RGZT.pdf |
| Part Number | TPA3101D2RGZT |
|---|---|
| Supplier Package | VQFN EP |
| Product Dimensions | 7 x 7 x 0.9 mm |
| Amplifier Type | Class-D |
| Pin Count | 48 |
| Maximum Load Resistance | 8 Ohm |
| Total Harmonic Distortion Noise | 0.09@8Ohm@5W % |
| Typical Voltage Gain | 36 dB |
| Mounting | Surface Mount |
| Maximum Power Dissipation | 4390 mW |
| Lead Finish | Gold |
| Input Signal Type | Differential |
| Output Type | 2-Channel Stereo |
| Typical PSRR | 70 dB |
| Typical Single Supply Voltage | 12|15|18|24 V |
| Typical Output Power x Channels @ Load | 10x2@8Ohm W |
| Output Signal Type | Differential |
| Max Processing Temp | 260 |
| Minimum Single Supply Voltage | 10 V |
| Operating Temperature | -40 to 85 °C |
| Rad Hard | No |
| Rail to Rail | No |
| Function | Speaker |
| Power Supply Type | Single |
| Maximum Single Supply Voltage | 26 V |
| MSL Level | 3 |
| Package | 48VQFN EP |
| Replacement Part Number | PART-TPA3101D2RGZT |
| Weight | Contact us |
| Country of Origin | - |
