Please contact us for more photos of TPD3S014TDBVRQ1
| Part Number | TPD3S014TDBVRQ1 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 713750 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Current Limit SW 2-IN 1-OUT 4.5V to 5.5V 0.5A 6-Pin SOT-23 T R |
| Category | Power Management IC |
| Family | Current Limit Switch |
| ROHS Compliant | Yes |
| MSL Level | TPD3S014TDBVRQ1 |
| Datasheet download |  TPD3S014TDBVRQ1.pdf |
| Part Number | TPD3S014TDBVRQ1 |
|---|---|
| Maximum Output Current | 0.5 A |
| Moisture Sensitivity Level | 2 |
| Screening Level | Automotive |
| Supplier Package | SOT-23 |
| Package Dimensions | 2.9 x 1.6 x 1.3 mm |
| Input Voltage | 4.5 to 5.5 V |
| Number of Outputs | 1 |
| Rad Hard | No |
| Mounting | Surface Mount |
| Maximum Processing Temperature | 260 °C |
| Operating Temperature | -40 to 105 °C |
| Pin Count | 6 |
| Lead Finish | Copper|Tin |
| Number of Inputs | 2 |
| Package | 6SOT-23 |
| Replacement Part Number | PART-TPD3S014TDBVRQ1 |
| Weight | Contact us |
| Country of Origin | - |
