Please contact us for more photos of TPS2813D
| Part Number | TPS2813D |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 339360 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MOSFET DRVR 2A 2-OUT High Speed Inv Non-Inv 8-Pin SOIC Tube |
| Category | Power Management IC |
| Family | MOSFET and Power Drivers |
| ROHS Compliant | Yes |
| MSL Level | TPS2813D |
| Datasheet download |  TPS2813D.pdf |
| Part Number | TPS2813D |
|---|---|
| Supplier Package | SOIC |
| Product Dimensions | 5 x 4 x 1.5 mm |
| Number of Drivers | 2 |
| Maximum Propagation Delay Time | 50 ns |
| Maximum Rise Time | 35 ns |
| Screening Level | Extended Industrial |
| Number of Outputs | 2 |
| Maximum Fall Time | 35 ns |
| Maximum Supply Current | 0.0002 mA |
| Input Logic Compatibility | CMOS |
| Max Processing Temp | 260 |
| Driver Type | High Speed |
| Rad Hard | No |
| Mounting | Surface Mount |
| Peak Output Current | 2 A |
| MSL Level | 1 |
| Maximum Power Dissipation | 730 mW |
| Maximum Operating Supply Voltage | 14 V |
| Pin Count | 8 |
| Driver Configuration | Inverting|Non-Inverting |
| Lead Finish | Gold |
| Minimum Operating Supply Voltage | 4 V |
| Operating Temperature | -40 to 125 °C |
| Package | 8SOIC |
| Replacement Part Number | PART-TPS2813D |
| Weight | Contact us |
| Country of Origin | - |
