Please contact us for more photos of TPS54020RUWR
| Part Number | TPS54020RUWR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 374390 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 1.6V to 17V 15-Pin VQFN T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | TPS54020RUWR |
| Datasheet download |  TPS54020RUWR.pdf |
| Part Number | TPS54020RUWR |
|---|---|
| Minimum Isolation Voltage | |
| Product Dimensions | 3.5 x 3.5 x 0.95(Max) |
| Lead Finish | Gold Over Nickel Palladium |
| Maximum Input Voltage | 17 V |
| Output Type | Adjustable |
| Switching Frequency | 200 to 1200 kHz |
| Operating Temperature | -40 to 150 °C |
| Rad Hard | No |
| Supplier Package | VQFN |
| Minimum Input Voltage | 1.6 V |
| Type | Step Down |
| Maximum Output Current | 10 A |
| Operating Supply Voltage | 1.6 to 17 V |
| Switching Regulator | Yes |
| Number of Outputs | 1 |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Output Voltage | 0.6 to 5 V |
| MSL Level | 1 |
| Pin Count | 15 |
| Package | 15VQFN |
| Replacement Part Number | PART-TPS54020RUWR |
| Weight | Contact us |
| Country of Origin | - |
