Please contact us for more photos of TPS563210DDFT
| Part Number | TPS563210DDFT |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 291940 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.5V to 17V 8-Pin SOT-23 T R |
| Category | Kits & Tools |
| Family | Development Kits |
| ROHS Compliant | Yes |
| MSL Level | TPS563210DDFT |
| Datasheet download |  TPS563210DDFT.pdf |
| Part Number | TPS563210DDFT |
|---|---|
| Type | Step Down |
| Minimum Input Voltage | 4.5 V |
| Switching Frequency | 650 kHz |
| Pin Count | 8 |
| Operating Supply Voltage | 4.5 to 17 V |
| Number of Outputs | 1 |
| Audio I/O | No |
| Supplier Package | SOT-23 |
| Output Type | Adjustable |
| Product Dimensions | 2.9 x 1.6 x 1(Max) |
| Maximum Input Voltage | 17 V |
| Ethernet | No |
| Screening Level | Industrial |
| Rad Hard | No |
| Mounting | Surface Mount |
| GPIO | No |
| Max Processing Temp | 260 |
| Maximum Output Current | 3 A |
| Lead Finish | Tin |
| Operating Temperature | -40 to 85 °C |
| Output Voltage | 0.76 to 7 V |
| MSL Level | 1 |
| Package | 8SOT-23 |
| Replacement Part Number | PART-TPS563210DDFT |
| Weight | Contact us |
| Country of Origin | - |
