Please contact us for more photos of TPS56C215RNNT
| Part Number | TPS56C215RNNT |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 733310 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.5V 17V 18-Pin VQFN EP T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | TPS56C215RNNT |
| Datasheet download |  TPS56C215RNNT.pdf |
| Part Number | TPS56C215RNNT |
|---|---|
| Output Voltage | 0.6 to 5.5 V |
| Package Dimensions | 3.5 x 3.5 x 0.95 mm |
| Rad Hard | No |
| Operating Supply Voltage | 4.5 to 17 V |
| Maximum Input Voltage | 17 V |
| Supplier Package | VQFN EP |
| Operating Temperature | -40 to 125 °C |
| Minimum Input Voltage | 4.5 V |
| Switching Frequency | 1200 kHz |
| Number of Outputs | 1 |
| Mounting | Surface Mount |
| Switching Regulator | Yes |
| Type | Step Down |
| Maximum Output Current | 12 A |
| Moisture Sensitivity Level | 2 |
| Lead Finish | Gold Over Nickel Palladium |
| Screening Level | Extended Industrial |
| Output Type | Adjustable |
| Pin Count | 18 |
| Maximum Processing Temperature | 260 °C |
| Package | 18VQFN EP |
| Replacement Part Number | PART-TPS56C215RNNT |
| Weight | Contact us |
| Country of Origin | - |
