Please contact us for more photos of TPS610986DSER
| Part Number | TPS610986DSER |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 256530 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Dual Step Up 0.7V to 4.5V 6-Pin WSON T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | TPS610986DSER |
| Datasheet download |  TPS610986DSER.pdf |
| Part Number | TPS610986DSER |
|---|---|
| Operating Supply Voltage | 0.7 to 4.5 V |
| Screening Level | Industrial |
| Maximum Input Voltage | 4.5 V |
| Operating Temperature | -40 to 85 °C |
| Maximum Processing Temperature | 260 °C |
| Number of Outputs | 2 |
| Switching Regulator | No |
| Output Type | Fixed |
| Type | Step Up |
| Mounting | Surface Mount |
| Efficiency | 88 % |
| Output Voltage | 3.3 V |
| Package Dimensions | 1.5 x 1.5 x 0.75 mm |
| Rad Hard | No |
| Maximum Output Current | 0.35 A |
| Supplier Package | WSON |
| Minimum Input Voltage | 0.7 V |
| Pin Count | 6 |
| Lead Finish | Gold Over Nickel Palladium |
| Moisture Sensitivity Level | 1 |
| Package | 6WSON |
| Replacement Part Number | PART-TPS610986DSER |
| Weight | Contact us |
| Country of Origin | - |
