Please contact us for more photos of TPS65023RSBR
| Part Number | TPS65023RSBR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 214380 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Power Management System Li-Ion Li-Pol 1700mA 0.6V to 6V 40-Pin WQFN EP T R |
| Category | Power Management IC |
| Family | Battery Management |
| ROHS Compliant | Yes |
| MSL Level | TPS65023RSBR |
| Datasheet download |  TPS65023RSBR.pdf |
| Part Number | TPS65023RSBR |
|---|---|
| Output Voltage | 0.6 to 6 V |
| Type | Power Management System |
| Pin Count | 40 |
| Output Current | 1700 mA |
| Product Dimensions | 5 x 5 x 0.75 mm |
| Battery Type | Li-Ion|Li-Pol |
| Operating Temperature | -40 to 85 °C |
| Lead Finish | Gold |
| MSL Level | 2 |
| Mounting | Surface Mount |
| Rad Hard | No |
| Supplier Package | WQFN EP |
| Max Processing Temp | 260 |
| Package | 40WQFN EP |
| Replacement Part Number | PART-TPS65023RSBR |
| Weight | Contact us |
| Country of Origin | - |
