Please contact us for more photos of TPS71533DCKR
| Part Number | TPS71533DCKR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 257060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | LDO Regulator Pos 3.3V 0.05A 5-Pin SC-70 T R |
| Category | Power Management IC |
| Family | Linear Regulator |
| ROHS Compliant | Yes |
| MSL Level | TPS71533DCKR |
| Datasheet download |  TPS71533DCKR.pdf |
| Part Number | TPS71533DCKR |
|---|---|
| Junction to Case | 165 °C/W |
| Output Type | Fixed |
| Accuracy | ±4 % |
| Product Dimensions | 2 x 1.25 x 0.9 mm |
| Maximum Dropout Voltage @ Current | 0.75@50mA V |
| Typical Quiescent Current | 0.0032 mA |
| Maximum Input Voltage | 24 V |
| Maximum Power Dissipation | 320 mW |
| Minimum Input Voltage | 2.5 V |
| Pin Count | 5 |
| Maximum Output Current | 0.05 A |
| Function | LDO |
| MSL Level | 1 |
| Mounting | Surface Mount |
| Number of Outputs | 1 |
| Screening Level | Extended |
| Max Processing Temp | 260 |
| Polarity | Positive |
| Supplier Package | SC-70 |
| Load Regulation | 22 mV |
| Input Voltage Range | 24 to 2.5 V |
| Operating Temperature | -40 to 125 °C |
| Line Regulation | 20 mV |
| Output Voltage | 3.3 V |
| Rad Hard | No |
| Typical Dropout Voltage @ Current | 0.415@50mA V |
| Junction to Ambient | 395 °C/W |
| Lead Finish | Gold |
| Package | 5SC-70 |
| Replacement Part Number | PART-TPS71533DCKR |
| Weight | Contact us |
| Country of Origin | - |
