TPS79718DCKR Texas Instruments

TPS79718DCKR Images

Please contact us for more photos of TPS79718DCKR

Part Number	TPS79718DCKR
Manufacturer	Texas Instruments
Quantity in stock	263980 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LDO Regulator Pos 1.8V 0.05A 5-Pin SC-70 T R
Category	Power Management IC
Family	Linear Regulator
ROHS Compliant	Yes
MSL Level	TPS79718DCKR
Datasheet download	TPS79718DCKR.pdf

Request Quotation for TPS79718DCKR

TPS79718DCKR Specifications

Part Number	TPS79718DCKR
Load Regulation	5 mV
MSL Level	1
Junction to Case	165.39 °C/W
Maximum Quiescent Current	0.002 mA
Rad Hard	No
Operating Temperature	-40 to 85 °C
Function	LDO
Output Voltage	1.8 V
Accuracy	±4 %
Number of Outputs	1
Mounting	Surface Mount
Max Processing Temp	260
Supplier Package	SC-70
Maximum Output Current	0.05 A
Pin Count	5
Product Dimensions	2 x 1.25 x 0.9 mm
Maximum Input Voltage	5.5 V
Minimum Input Voltage	1.8 V
Maximum Power Dissipation	318 mW
Output Type	Fixed
Screening Level	Industrial
Input Voltage Range	5.5 to 1.8 V
Polarity	Positive
Lead Finish	Gold
Typical Quiescent Current	0.0012 mA
Junction to Ambient	396.24 °C/W
Line Regulation	0.15 %/V
Package	5SC-70
Replacement Part Number	PART-TPS79718DCKR
Weight	Contact us
Country of Origin	-
