UCC25230DRMR Texas Instruments

UCC25230DRMR Images

Please contact us for more photos of UCC25230DRMR

Part Number UCC25230DRMR
Manufacturer Texas Instruments
Quantity in stock 417550 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Conv DC-DC Single Step Down 12V to 100V 8-Pin VSON EP T R
Category Power Management IC
Family DC to DC Converter
ROHS Compliant Yes
MSL Level UCC25230DRMR
Datasheet download UCC25230DRMR.pdf
Request Quotation for UCC25230DRMR

UCC25230DRMR Specifications

Part Number UCC25230DRMR
Line Regulation 40 mV
Switching Frequency 380 kHz
Operating Supply Voltage 12 to 100 V
Supplier Package VSON EP
Output Voltage 9 V
Type Step Down
Max Processing Temp 260
Output Type Adjustable
Maximum Input Voltage 100 V
Product Dimensions 4 x 4 x 0.9 mm
Minimum Input Voltage 12 V
Maximum Output Current 0.2 A
Rad Hard No
Mounting Surface Mount
MSL Level 1
Pin Count 8
Number of Outputs 1
Load Regulation 40 mV
Switching Regulator Yes
Lead Finish Gold
Operating Temperature -40 to 125 °C
Package 8VSON EP
Replacement Part Number PART-UCC25230DRMR
Weight Contact us
Country of Origin -
