Please contact us for more photos of HCPL-070L-560E
| Part Number | HCPL-070L-560E |
|---|---|
| Manufacturer | Broadcom |
| Quantity in stock | 123800 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Optocoupler DC-IN 1-CH Darlington With Base DC-OUT 8-Pin SOIC T R |
| Category | Optoelectronics |
| Family | OptoCouplers |
| ROHS Compliant | Yes |
| MSL Level | HCPL-070L-560E |
| Datasheet download |  HCPL-070L-560E.pdf |
| Part Number | HCPL-070L-560E |
|---|---|
| Max Processing Temp | 260 |
| Rad Hard | No |
| Operating Temperature | 0 to 70 °C |
| Maximum Collector Current | 60 mA |
| Maximum Forward Voltage | 1.7 V |
| Typical Forward Voltage | 1.5 V |
| Minimum Isolation Voltage | 3750 Vrms |
| Maximum Power Dissipation | 135 mW |
| Maximum Input Current | 20 mA |
| Mounting | Surface Mount |
| Maximum Reverse Voltage | 5 V |
| Lead Finish | Matte Tin |
| Output Type | DC |
| Input Type | DC |
| Maximum Current Transfer Ratio @ Current | 5000 % |
| Product Dimensions | 5.08 x 3.94 x 3.18 mm |
| MSL Level | 1 |
| Pin Count | 8 |
| Number of Channels per Chip | 1 |
| Supplier Package | SOIC |
| Package | 8SOIC |
| Replacement Part Number | PART-HCPL-070L-560E |
| Weight | Contact us |
| Country of Origin | - |
