Please contact us for more photos of MOC3023M
| Part Number | MOC3023M |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 563110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Optocoupler Triac AC-OUT 1-CH 400VDRM 6-Pin PDIP White Bulk |
| Category | Optoelectronics |
| Family | OptoCouplers |
| ROHS Compliant | Yes |
| MSL Level | MOC3023M |
| Datasheet download |  MOC3023M.pdf |
| Part Number | MOC3023M |
|---|---|
| Mounting | Through Hole |
| Peak Output Voltage (Vdrm) | 400 V |
| Operating Temperature | -40 to 85 °C |
| Typical Input Voltage | 1.15 V |
| Rad Hard | No |
| Lead Finish | Matte Tin |
| Output Type | AC |
| Pin Count | 6 |
| Number of Channels per Chip | 1 |
| Max Processing Temp | 260 |
| Maximum Reverse Voltage | 3 V |
| Product Dimensions | 8.89 x 6.6 x 3.53 mm |
| Supplier Package | PDIP White |
| Maximum Input Voltage | 1.5 V |
| Zero-Crossing Circuit | No |
| Minimum Isolation Voltage | 5300 Vrms |
| Maximum Output Voltage | 280 Vac |
| Package | 6PDIP White |
| Replacement Part Number | PART-MOC3023M |
| Weight | Contact us |
| Country of Origin | - |
