Please contact us for more photos of 615R100GAD33
| Part Number | 615R100GAD33 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 414190 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 0.0033uF 10000V Z5U -20% to 80% (24.9 X 9.9mm) Radial 12.7mm 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Ceramic Singlelayer |
| ROHS Compliant | Yes |
| MSL Level | 615R100GAD33 |
| Datasheet download |  615R100GAD33.pdf |
| Part Number | 615R100GAD33 |
|---|---|
| Operating Temperature | -25 to 105 °C |
| Capacitance Value | 0.0033 uF |
| Termination Style | Radial |
| Package/Case | 24.9(Max) X 9.9(Max) |
| Tolerance | -20 to 80 % |
| Lead Pitch For Radial | 12.7 mm |
| Product Dimensions | 9.9 mm |
| Rad Hard | No |
| Seated Plane Height | 29.7 mm |
| Dielectric | Z5U |
| Voltage(DC) | 10 kV |
| Mounting | Through Hole |
| Lead Finish | Tin |
| Product Depth | 9.9(Max) mm |
| Product Diameter | 24.9(Max) mm |
| Replacement Part Number | PART-615R100GAD33 |
| Weight | Contact us |
| Country of Origin | - |
