Please contact us for more photos of LPS0800H1500KB
| Part Number | LPS0800H1500KB |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 118440 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 150 Ohm 10% 800W \u00b1150ppm \u00b0C Molded Screw Terminal Bolt-On Box |
| Category | Resistor |
| Family | Resistor Misc |
| ROHS Compliant | Yes |
| MSL Level | LPS0800H1500KB |
| Datasheet download |  LPS0800H1500KB.pdf |
| Part Number | LPS0800H1500KB |
|---|---|
| Resistance Value | 150 Ohm |
| Termination Style | Screw Terminal |
| Temperature Coefficient | ±150 ppm/°C |
| Lead Finish | Pure Tin |
| Rad Hard | No |
| Product Dimensions | 64.7 x 57 x 25.8 |
| Type | Thick Film |
| Operating Temperature | -55 to 175 °C |
| Tolerance | 10 % |
| Case Style | Molded |
| Package Type | |
| Military Standard | |
| Pin Count | 2 |
| Mounting | Bolt-On |
| Power Rating | 800 W |
| Failure Rate | |
| Product Depth | 57 mm |
| Product Height | 25.8 mm |
| Product Length | 64.7 mm |
| Product Weight | 83 G |
| Replacement Part Number | PART-LPS0800H1500KB |
| Weight | Contact us |
| Country of Origin | - |
