Please contact us for more photos of MPMT1002AT1
| Part Number | MPMT1002AT1 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 893150 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thin Film NET 5K Ohm 5K Ohm 0.1% 1 5W \u00b125ppm \u00b0C VOLT D Molded 3-Pin SOT-23 Gull Wing SMD T R |
| Category | Resistor |
| Family | Resistor Networks and Arrays |
| ROHS Compliant | Yes |
| MSL Level | MPMT1002AT1 |
| Datasheet download |  MPMT1002AT1.pdf |
| Part Number | MPMT1002AT1 |
|---|---|
| Technology | Thin Film |
| Product Dimensions | 3.05 x 2.5 x 1.12 mm |
| Temperature Coefficient | ±25 ppm/°C |
| Tolerance | 0.1 % |
| Circuit Designator | VOLT/D |
| Number of Terminals | 3 |
| Max Processing Temp | 260 |
| Power Rating | 0.2 W |
| Power Rating per Resistor | 1/10 W |
| Type | Network |
| Resistance Value | 5 kOhm |
| Lead Finish | Matte Tin |
| Operating Temperature | -55 to 125 °C |
| Rad Hard | No |
| Termination Style | Gull Wing |
| MSL Level | 1 |
| Number of Resistors | 2 |
| Package Type | SOT-23 |
| Case Style | Molded |
| Mounting | Surface Mount |
| Product Depth | 2.5 mm |
| Product Height | 1.12 mm |
| Product Length | 3.05 mm |
| Replacement Part Number | PART-MPMT1002AT1 |
| Weight | Contact us |
| Country of Origin | - |
