Please contact us for more photos of T55B226M016C0070
| Part Number | T55B226M016C0070 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 570170 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 22uF 16V B CASE 20% (3.5 X 2.8 X 1.9mm) SMD 3528-21 0.07 Ohm 105\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | T55B226M016C0070 |
| Datasheet download |  T55B226M016C0070.pdf |
| Part Number | T55B226M016C0070 |
|---|---|
| Rad Hard | No |
| Construction | Flat |
| Mounting | Surface Mount |
| Package/Case | 3528-21,B |
| MSL Level | 3 |
| Voltage(DC) | 16 V |
| Case Style | Molded |
| Polarity | Polar |
| Leakage Current | 35.2 uA |
| Max Processing Temp | 260 |
| Lead Finish | Gold Over Nickel Palladium |
| Operating Temperature | -55 to 105 °C |
| Case Code | B |
| Supplier Package | 1411 |
| Dissipation Factor | 10 |
| Product Dimensions | 3.5 x 2.8 x 1.9 |
| Equivalent Series Resistance | 0.07 Ohm |
| Tolerance | 20 % |
| Case Size | 1411 |
| Capacitance Value | 22 uF |
| Pin Count | 2 |
| Product Depth | 2.8 mm |
| Product Height | 1.9 mm |
| Product Length | 3.5 mm |
| Replacement Part Number | PART-T55B226M016C0070 |
| Weight | Contact us |
| Country of Origin | - |
