Please contact us for more photos of T55V476M016C0045
| Part Number | T55V476M016C0045 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 248690 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 47uF 16V V CASE 20% (7.3 X 4.3 X 1.9mm) SMD 7343-20 0.045 Ohm 105\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | T55V476M016C0045 |
| Datasheet download |  T55V476M016C0045.pdf |
| Part Number | T55V476M016C0045 |
|---|---|
| Leakage Current | 75.2 uA |
| Construction | Flat |
| Capacitance Value | 47 uF |
| Lead Finish | Gold Over Nickel Palladium |
| Package/Case | 7343-20,V |
| Equivalent Series Resistance | 0.045 Ohm |
| Mounting | Surface Mount |
| Voltage(DC) | 16 V |
| Polarity | Polar |
| Moisture Sensitivity Level | 3 |
| Case Size | 2917 |
| Operating Temperature | -55 to 105 °C |
| Case Style | Molded |
| Package Dimensions | 7.3 x 4.3 x 1.9 mm |
| Pin Count | 2 |
| Supplier Package | 2917 |
| Maximum Processing Temperature | 260 °C |
| Rad Hard | No |
| Tolerance | 20 % |
| Dissipation Factor | 10 |
| Product Depth | 4.3 mm |
| Product Height | 1.9 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-T55V476M016C0045 |
| Weight | Contact us |
| Country of Origin | - |
