Please contact us for more photos of TL3B476M010C0600
| Part Number | TL3B476M010C0600 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 416680 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 47uF 10V B CASE 20% (3.5 X 2.8 X 1.9mm) SMD 3528-21 0.6 Ohm 125\u00b0C Embossed Plastic T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | TL3B476M010C0600 |
| Datasheet download |  TL3B476M010C0600.pdf |
| Part Number | TL3B476M010C0600 |
|---|---|
| Polarity | Polar |
| Construction | Flat |
| Lead Finish | Matte Tin |
| Package/Case | 3528-21,B |
| MSL Level | 1 |
| Capacitance Value | 47 uF |
| Operating Temperature | -55 to 125 °C |
| Voltage(DC) | 10 V |
| Mounting | Surface Mount |
| Supplier Package | 1411 |
| Leakage Current | 2.35@5Min uA |
| Equivalent Series Resistance | 0.6 Ohm |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Tolerance | 20 % |
| Case Style | Molded |
| Pin Count | 2 |
| Case Size | 1411 |
| Dissipation Factor | 6 % |
| Case Code | B |
| Product Dimensions | 3.5 x 2.8 x 1.9 |
| Product Depth | 2.8 mm |
| Product Height | 1.9 mm |
| Product Length | 3.5 mm |
| Replacement Part Number | PART-TL3B476M010C0600 |
| Weight | Contact us |
| Country of Origin | - |
