Please contact us for more photos of TS6Y222KT20
| Part Number | TS6Y222KT20 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 217720 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Cermet Trimmer 2.2K Ohm 10% 1 4W 14(Elec) 15(Mech)Turn 1.8mm (6.85 X 6.7 X 8mm) Gull Wing SMD Tube |
| Category | Resistor |
| Family | Resistor Trimmers, Potentiometers and Rheostats |
| ROHS Compliant | Yes |
| MSL Level | TS6Y222KT20 |
| Datasheet download |  TS6Y222KT20.pdf |
| Part Number | TS6Y222KT20 |
|---|---|
| Product Dimensions | 6.85 x 6.7 x 8 mm |
| Resistance Value | 2.2 kOhm |
| Mounting | Surface Mount |
| Power Rating | 0.25 W |
| Temperature Coefficient | ±100 ppm |
| Max Processing Temp | 220 |
| Technology | Cermet |
| Shaft Diameter | 1.8 mm |
| Operating Temperature | -55 to 155 °C |
| Termination Style | Gull Wing |
| Package Type | Surface Mount/Gull Wing |
| Rad Hard | No |
| Tolerance | 10 % |
| Type | Trimmer |
| Number of Turns | 14(Elec)|15(Mech) |
| Product Depth | 6.7 mm |
| Product Height | 8 mm |
| Product Length | 6.85 mm |
| Replacement Part Number | PART-TS6Y222KT20 |
| Weight | Contact us |
| Country of Origin | - |
