Please contact us for more photos of TSOP77438WTR
| Part Number | TSOP77438WTR |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 175040 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | IR Remote Receiver 38KHz 35m 8-Pin SMD T R |
| Category | Interface IC |
| Family | IR Remote Receiver |
| ROHS Compliant | Yes |
| MSL Level | TSOP77438WTR |
| Datasheet download |  TSOP77438WTR.pdf |
| Part Number | TSOP77438WTR |
|---|---|
| Package Dimensions | 6.8 x 2.35 x 3 mm |
| Supply Current | 0.9 mA |
| Rad Hard | No |
| Supplier Package | SMD |
| Output Current | 5 mA |
| Moisture Sensitivity Level | 4 |
| Viewing Orientation | 150 ° |
| Maximum Processing Temperature | 260 °C |
| Power Dissipation | 10 mW |
| Operating Temperature | -25 to 85 °C |
| Transmission Distance | 35 m |
| Pin Count | 4 |
| Screening Level | Industrial |
| Carrier Frequency | 38 kHz |
| Operating Supply Voltage | 2.5 to 5.5 V |
| Mounting | Surface Mount |
| Package | 4SMD |
| Replacement Part Number | PART-TSOP77438WTR |
| Weight | Contact us |
| Country of Origin | - |
