TSTA7300 Vishay

Please contact us for more photos of TSTA7300

Part Number	TSTA7300
Manufacturer	Vishay
Quantity in stock	351270 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED IrLED 870nm 2-Pin TO-18
Category	Lighting
Family	LEDs
ROHS Compliant	Yes
MSL Level	TSTA7300
Datasheet download	TSTA7300.pdf

Request Quotation for TSTA7300

TSTA7300 Specifications

Part Number	TSTA7300
Maximum Power Dissipation	500
Intensity	20
Peak Wavelength	870 nm
Viewing Angle	24 °
Mounting Orientation	Top Mount
Operating Temperature	N/A to 100 °C
Category	IrLED
Lead Finish	Silver
Maximum Forward Current	100
Lens Shape Type	Circular
Product Dimensions	5.5 x 5.5 x 6.15 mm
Reverse Voltage	5 V
Mounting	Through Hole
Number of LEDs	1
Type	IrLED
LED Material	GaAlAs
Rad Hard	No
Maximum Forward Voltage per Color	1.8
Pin Count	2
Supplier Package	TO-18
Package	2TO-18
Replacement Part Number	PART-TSTA7300
Weight	Contact us
Country of Origin	-
