VJ1206A471JXBAT Vishay

VJ1206A471JXBAT Images

Please contact us for more photos of VJ1206A471JXBAT

Part Number VJ1206A471JXBAT
Manufacturer Vishay
Quantity in stock 174880 Pieces
Market Price -
Our Better Price Send by email: sales@part-elec.com
Delivery Time 1 day (can ship today)
Description Cap Ceramic 470pF 100V C0G 5% SMD 1206 150\u00b0C Plastic T R
Category Capacitors
Family Capacitor Ceramic Multilayer
ROHS Compliant Yes
MSL Level VJ1206A471JXBAT
Datasheet download VJ1206A471JXBAT.pdf
Request Quotation for VJ1206A471JXBAT

VJ1206A471JXBAT Specifications

Part Number VJ1206A471JXBAT
Package/Case 1206
Lead Finish Matte Tin
Capacitance Value 470 pF
Case Size 1206
Rad Hard No
MSL Level 1
Tolerance 5 %
Dielectric C0G
Mounting Surface Mount
Max Processing Temp 235 to 260|260
Construction Flat
Product Dimensions 3.2 x 1.6 x 1.7 mm
Operating Temperature -55 to 150 °C
Voltage(DC) 100 V
Case Style Ceramic Chip
Product Depth 1.6 mm
Product Height 1.7(Max) mm
Product Length 3.2 mm
Replacement Part Number PART-VJ1206A471JXBAT
Weight Contact us
Country of Origin -
