Please contact us for more photos of UC2524ADWTR
| Part Number | UC2524ADWTR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 159350 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Voltage Mode PWM Controller 60V 200mA 16-Pin SOIC T R |
| Category | Power Management IC |
| Family | PWM Controllers |
| ROHS Compliant | Yes |
| MSL Level | UC2524ADWTR |
| Datasheet download |  UC2524ADWTR.pdf |
| Part Number | UC2524ADWTR |
|---|---|
| Supplier Package | SOIC |
| Topology | Boost|Flyback|Forward|Full-Bridge|Half-Bridge|Push-Pull |
| Product Dimensions | 10.28 x 7.52 x 2.35 mm |
| On/Off Pin | Yes |
| Adjustable Output | No |
| Max Processing Temp | 260 |
| Synchronous Pin | Yes |
| Number of PWM Outputs | 2 |
| Pin Count | 16 |
| Operating Temperature | -40 to 85 °C |
| Maximum Duty Cycle | 45(Min) % |
| Rad Hard | No |
| Mounting | Surface Mount |
| Output Voltage | 60 V |
| Lead Finish | Gold |
| Switching Frequency | 500 kHz |
| Output Current | 200 mA |
| MSL Level | 2 |
| Package | 16SOIC |
| Replacement Part Number | PART-UC2524ADWTR |
| Weight | Contact us |
| Country of Origin | - |
