Please contact us for more photos of XC2S30-5CSG144I
| Part Number | XC2S30-5CSG144I |
|---|---|
| Manufacturer | Xilinx |
| Quantity in stock | 177030 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | FPGA Spartan\u00ae-II Family 30K Gates 972 Cells 263MHz 0.18um Technology 2.5V 144-Pin CS-BGA |
| Category | Programmable Logic IC |
| Family | FPGA |
| ROHS Compliant | Yes |
| MSL Level | XC2S30-5CSG144I |
| Datasheet download |  XC2S30-5CSG144I.pdf |
| Part Number | XC2S30-5CSG144I |
|---|---|
| In System Programmability | No |
| Mounting | Surface Mount |
| Fabrication Technology | 0.18um |
| Re-programmability Support | Yes |
| Typical Operating Supply Voltage | 2.5 V |
| Maximum Operating Supply Voltage | 2.625 V |
| Supplier Package | CSBGA |
| Maximum Internal Frequency | 263 MHz |
| Screening Level | Industrial |
| Pin Count | 144 |
| Operating Temperature | -40 to 100 °C |
| Device Logic Gates | 30000 |
| Device System Gates | 30000 |
| RAM Bits | 24576 |
| Device Logic Units | 216 |
| Rad Hard | No |
| Maximum Number of User I/Os | 92 |
| Lead Finish | Tin/Silver/Copper |
| Max Processing Temp | 260 |
| Speed Grade | 5 |
| Product Dimensions | 12 x 12 x 0.65 mm |
| Device Logic Cells | 972 |
| Minimum Operating Supply Voltage | 2.375 V |
| MSL Level | 3 |
| Package | 144CS-BGA |
| Replacement Part Number | PART-XC2S30-5CSG144I |
| Weight | Contact us |
| Country of Origin | - |
