Please contact us for more photos of XC3S1500-4FG456C
| Part Number | XC3S1500-4FG456C |
|---|---|
| Manufacturer | Xilinx |
| Quantity in stock | 592040 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | FPGA Spartan\u00ae-3 Family 1.5M Gates 29952 Cells 630MHz 90nm Technology 1.2V 456-Pin F-BGA |
| Category | Programmable Logic IC |
| Family | FPGA |
| ROHS Compliant | Yes |
| MSL Level | XC3S1500-4FG456C |
| Datasheet download |  XC3S1500-4FG456C.pdf |
| Part Number | XC3S1500-4FG456C |
|---|---|
| Maximum Internal Frequency | 630 MHz |
| In System Programmability | Yes |
| Device System Gates | 1500000 |
| Device Logic Gates | 1500000 |
| Maximum Number of User I/Os | 333 |
| Product Dimensions | 23 x 23 x 2 mm |
| Device Logic Units | 29952 |
| Operating Temperature | 0 to 85 °C |
| MSL Level | 3 |
| Device Logic Cells | 29952 |
| Minimum Operating Supply Voltage | 1.14 V |
| Re-programmability Support | Yes |
| Fabrication Technology | 90nm |
| Supplier Package | FBGA |
| RAM Bits | 589824 |
| Speed Grade | 4 |
| Pin Count | 456 |
| Maximum Operating Supply Voltage | 1.26 V |
| Typical Operating Supply Voltage | 1.2 V |
| Max Processing Temp | 225 |
| Screening Level | Commercial |
| Mounting | Surface Mount |
| Lead Finish | Tin/Lead |
| Rad Hard | No |
| Package | 456F-BGA |
| Replacement Part Number | PART-XC3S1500-4FG456C |
| Weight | Contact us |
| Country of Origin | - |
