Please contact us for more photos of XC3SD1800A-4CSG484I
| Part Number | XC3SD1800A-4CSG484I |
|---|---|
| Manufacturer | Xilinx |
| Quantity in stock | 454610 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | FPGA Spartan\u00ae-3A DSP Family 1.8M Gates 37440 Cells 667MHz 90nm Technology 1.2V 484-Pin LCSBGA |
| Category | Programmable Logic IC |
| Family | FPGA |
| ROHS Compliant | Yes |
| MSL Level | XC3SD1800A-4CSG484I |
| Datasheet download |  XC3SD1800A-4CSG484I.pdf |
| Part Number | XC3SD1800A-4CSG484I |
|---|---|
| In System Programmability | No |
| Mounting | Surface Mount |
| Device System Gates | 1800000 |
| Supplier Package | LCSBGA |
| Device Logic Gates | 1800000 |
| Maximum Number of User I/Os | 309 |
| Maximum Internal Frequency | 667 MHz |
| RAM Bits | 1548288 |
| Device Logic Units | 37440 |
| Device Logic Cells | 37440 |
| Operating Temperature | -40 to 100 °C |
| MSL Level | 3 |
| Lead Finish | Tin/Silver/Copper |
| Fabrication Technology | 90nm |
| Pin Count | 484 |
| Minimum Operating Supply Voltage | 1.14 V |
| Re-programmability Support | Yes |
| Product Dimensions | 19 x 19 x 1.35 mm |
| Speed Grade | 4 |
| Maximum Operating Supply Voltage | 1.26 V |
| Typical Operating Supply Voltage | 1.2 V |
| Screening Level | Industrial |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Package | 484LCSBGA |
| Replacement Part Number | PART-XC3SD1800A-4CSG484I |
| Weight | Contact us |
| Country of Origin | - |
