Please contact us for more photos of XC6SLX100-3FGG676I
| Part Number | XC6SLX100-3FGG676I |
|---|---|
| Manufacturer | Xilinx |
| Quantity in stock | 745720 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | FPGA Spartan\u00ae-6 LX Family 101261 Cells 45nm (CMOS) Technology 1.2V 676-Pin FBGA |
| Category | Programmable Logic IC |
| Family | FPGA |
| ROHS Compliant | Yes |
| MSL Level | XC6SLX100-3FGG676I |
| Datasheet download |  XC6SLX100-3FGG676I.pdf |
| Part Number | XC6SLX100-3FGG676I |
|---|---|
| In System Programmability | No |
| Pin Count | 676 |
| Mounting | Surface Mount |
| Device Logic Units | 101261 |
| Typical Operating Supply Voltage | 1.2 V |
| RAM Bits | 4939776 |
| Re-programmability Support | Yes |
| Supplier Package | FBGA |
| Fabrication Technology | 45nm (CMOS) |
| Speed Grade | 3 |
| Maximum Operating Supply Voltage | 1.26 V |
| Screening Level | Industrial |
| Product Dimensions | 27 x 27 x 1.75 mm |
| Operating Temperature | -40 to 100 °C |
| Device Logic Cells | 101261 |
| Number of Registers | 126576 |
| Lead Finish | Tin/Silver/Copper |
| Maximum Number of User I/Os | 480 |
| Maximum Propagation Delay Time | 1.28 |
| Minimum Operating Supply Voltage | 1.14 V |
| Rad Hard | No |
| MSL Level | 3 |
| Max Processing Temp | 250 |
| Package | 676FBGA |
| Replacement Part Number | PART-XC6SLX100-3FGG676I |
| Weight | Contact us |
| Country of Origin | - |
