1N4740ATR Fairchild Semiconductor

1N4740ATR Images

Please contact us for more photos of 1N4740ATR

Part Number 1N4740ATR
Manufacturer Fairchild Semiconductor
Quantity in stock 331010 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Zener Single 10V 5% 1W 2-Pin DO-41 T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level 1N4740ATR
Datasheet download 1N4740ATR.pdf
Request Quotation for 1N4740ATR

1N4740ATR Specifications

Part Number 1N4740ATR
Product Dimensions 5.21 x 2.72 x 2.72 mm
Operating Temperature -65 to 200 °C
Supplier Package DO-41
Configuration Single
Maximum Reverse Leakage Current 10 uA
Maximum Zener Impedance 7 Ohm
Test Current 25 mA
Pin Count 2
Mounting Through Hole
Rad Hard No
Lead Finish Matte Tin
Nominal Zener Voltage 10 V
ESD Protection No
Zener Voltage Tolerance 5 %
Maximum Power Dissipation 1000 mW
Package 2DO-41
Replacement Part Number PART-1N4740ATR
Weight Contact us
Country of Origin -
