Please contact us for more photos of 1N5343BRLG
| Part Number | 1N5343BRLG |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 455180 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 7.5V 5% 5W 2-Pin Case 017AA-01 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | 1N5343BRLG |
| Datasheet download |  1N5343BRLG.pdf |
| Part Number | 1N5343BRLG |
|---|---|
| Lead Finish | Matte Tin |
| Zener Voltage Tolerance | 5 % |
| Test Current | 175 mA |
| Maximum Zener Impedance | 1.5 Ohm |
| Type | Voltage Regulator |
| Nominal Zener Voltage | 7.5 V |
| Maximum Voltage Regulation | 150 mV |
| Mounting | Through Hole |
| Supplier Package | Case 017AA-01 |
| Maximum Regulator Current | 630 mA |
| ESD Protection | Yes |
| Product Dimensions | 8.89 x 3.68 x 3.68 mm |
| Pin Count | 2 |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Configuration | Single |
| Operating Temperature | -65 to 150 °C |
| Maximum Power Dissipation | 5000 mW |
| Maximum Reverse Leakage Current | 10 uA |
| Package | 2Case 017AA-01 |
| Replacement Part Number | PART-1N5343BRLG |
| Weight | Contact us |
| Country of Origin | - |
