Please contact us for more photos of BZT52C18-7-F
| Part Number | BZT52C18-7-F |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 466270 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 18V 6% 370mW 2-Pin SOD-123 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BZT52C18-7-F |
| Datasheet download |  BZT52C18-7-F.pdf |
| Part Number | BZT52C18-7-F |
|---|---|
| Supplier Package | SOD-123 |
| Maximum Power Dissipation | 370 mW |
| Maximum Zener Impedance | 45 Ohm |
| Operating Temperature | -65 to 150 °C |
| Screening Level | Commercial |
| Test Current | 5 mA |
| Max Processing Temp | 260 |
| Pin Count | 2 |
| Typical Voltage Temperature Coefficient | 14.2 mV/°C |
| ESD Protection | No |
| Maximum Reverse Leakage Current | 0.1 uA |
| Nominal Zener Voltage | 18 V |
| Lead Finish | Matte Tin |
| Zener Voltage Tolerance | 6 % |
| MSL Level | 1 |
| Rad Hard | No |
| Mounting | Surface Mount |
| Configuration | Single |
| Product Dimensions | 2.85 x 1.7 x 1.35 mm |
| Package | 2SOD-123 |
| Replacement Part Number | PART-BZT52C18-7-F |
| Weight | Contact us |
| Country of Origin | - |
