Please contact us for more photos of BZX884-B8V2,315
| Part Number | BZX884-B8V2,315 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 530060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 8.2V 2% 250mW 2-Pin SOD-882 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BZX884-B8V2,315 |
| Datasheet download |  BZX884-B8V2,315.pdf |
| Part Number | BZX884-B8V2,315 |
|---|---|
| Test Current | 5 mA |
| Operating Temperature | -65 to 150 °C |
| Typical Voltage Temperature Coefficient | 4.3 mV/K |
| Maximum Reverse Leakage Current | 0.7 uA |
| Maximum Zener Impedance | 10 Ohm |
| Maximum Power Dissipation | 250 mW |
| Max Processing Temp | 260 |
| Zener Voltage Tolerance | 2 % |
| Supplier Package | SOD-882 |
| Pin Count | 2 |
| ESD Protection | Yes |
| Configuration | Single |
| Rad Hard | No |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Product Dimensions | 1.02 x 0.62 x 0.47 mm |
| Type | Voltage Regulator |
| Nominal Zener Voltage | 8.2 V |
| Lead Finish | Tin |
| Package | 2SOD-882 |
| Replacement Part Number | PART-BZX884-B8V2,315 |
| Weight | Contact us |
| Country of Origin | - |
