Please contact us for more photos of DDZ9688-7
| Part Number | DDZ9688-7 |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 367600 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 4.7V 5% 500mW 2-Pin SOD-123 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | DDZ9688-7 |
| Datasheet download |  DDZ9688-7.pdf |
| Part Number | DDZ9688-7 |
|---|---|
| Configuration | Single |
| Pin Count | 2 |
| Rad Hard | No |
| Nominal Zener Voltage | 4.7 V |
| Max Processing Temp | 260 |
| Maximum Reverse Leakage Current | 5 uA |
| Operating Temperature | -65 to 150 °C |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Product Dimensions | 2.85 x 1.7 x 1.35 mm |
| Supplier Package | SOD-123 |
| Maximum Power Dissipation | 500 mW |
| Zener Voltage Tolerance | 5 % |
| MSL Level | 1 |
| ESD Protection | No |
| Test Current | 0.05 mA |
| Package | 2SOD-123 |
| Replacement Part Number | PART-DDZ9688-7 |
| Weight | Contact us |
| Country of Origin | - |
