Please contact us for more photos of LBZT52C3V6T1G
| Part Number | LBZT52C3V6T1G |
|---|---|
| Manufacturer | Leshan Radio |
| Quantity in stock | 389020 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 3.6V 500mW 2-Pin SOD-123 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | LBZT52C3V6T1G |
| Datasheet download |  LBZT52C3V6T1G.pdf |
| Part Number | LBZT52C3V6T1G |
|---|---|
| Typical Voltage Temperature Coefficient | -1.75 mV/°C |
| Pin Count | 2 |
| Rad Hard | No |
| Configuration | Single |
| Maximum Reverse Leakage Current | 5 uA |
| Test Current | 5 mA |
| Operating Temperature | -65 to 150 °C |
| Type | Voltage Regulator |
| Mounting | Surface Mount |
| Supplier Package | SOD-123 |
| Maximum Regulator Current | 5 mA |
| Maximum Power Dissipation | 500 mW |
| Maximum Zener Impedance | 90 Ohm |
| Package Dimensions | 2.85 x 1.8 x 1.35 mm |
| Nominal Zener Voltage | 3.6 V |
| ESD Protection | No |
| Package | 2SOD-123 |
| Replacement Part Number | PART-LBZT52C3V6T1G |
| Weight | Contact us |
| Country of Origin | - |
