Please contact us for more photos of LUDZS7.5BT1G
| Part Number | LUDZS7.5BT1G |
|---|---|
| Manufacturer | Leshan Radio |
| Quantity in stock | 196190 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 7.44V 200mW 2-Pin SOD-323 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | LUDZS7.5BT1G |
| Datasheet download |  LUDZS7.5BT1G.pdf |
| Part Number | LUDZS7.5BT1G |
|---|---|
| Mounting | Surface Mount |
| Supplier Package | SOD-323 |
| Package Dimensions | 1.8 x 1.35 x 1 mm |
| ESD Protection | Yes |
| Nominal Zener Voltage | 7.44 V |
| Type | Voltage Regulator |
| Maximum Zener Impedance | 30 Ohm |
| Operating Temperature | -55 to 150 °C |
| Pin Count | 2 |
| Configuration | Single |
| Rad Hard | No |
| Maximum Reverse Leakage Current | 0.5 uA |
| Maximum Power Dissipation | 200 mW |
| Test Current | 5 mA |
| Package | 2SOD-323 |
| Replacement Part Number | PART-LUDZS7.5BT1G |
| Weight | Contact us |
| Country of Origin | - |
